Hydraulic Cylinders & Custom Hydraulic Solutions – Up to 700 mm Bore, 6 m Stroke & 500 Tonne Capacity

AKURACY.ORG Hydraulic Cylinders are engineered for demanding industrial lifting, pressing, pushing, pulling, material-handling and automation applications. We offer standard as well as custom hydraulic cylinder solutions manufactured according to application requirements for bore size, stroke length, capacity, mounting arrangement, operating action and installation conditions.

Our hydraulic cylinder range includes single acting hydraulic cylinders, double acting hydraulic cylinders, telescopic hydraulic cylinders, trunnion mounted cylinders, flange mounted cylinders, clevis mounted cylinders, press cylinders, lift cylinders, stacker cylinders and scissor-lift cylinders.

Key Capacity Range

• Bore Size: Up to 700 mm

• Stroke Length: Up to 6 metres

• Capacity: Up to 500 tonne

• Mounting: Trunnion, flange, clevis and customized mounting

• Acting Type: Single Acting / Double Acting

• Cylinder Type: Standard / Telescopic / Application-Specific

• Configuration: Customized as per customer requirement

• Price: On Request

Working pressure and detailed hydraulic specifications are selected according to cylinder size, load, application and customer requirements.

Hydraulic Cylinder Product Range

1. Trunnion Mounted Hydraulic Cylinder

A trunnion mounted hydraulic cylinder is suitable for applications where the cylinder needs to pivot during operation. The mounting arrangement allows controlled angular movement and makes this configuration suitable for industrial lifting equipment, material-handling machinery, presses and special-purpose hydraulic systems.

Available: Bore up to 700 mm | Stroke up to 6 m | Capacity up to 500 tonne | Customized sizes available.

2. Flange Mounted Hydraulic Cylinder

Our flange mounted hydraulic cylinders provide a rigid and secure mounting arrangement for industrial equipment requiring controlled linear force. They are suitable for hydraulic presses, production machinery, automation equipment and heavy-duty industrial systems.

Front flange, rear flange and application-specific mounting arrangements can be considered according to customer requirements.

3. Clevis Mounted Hydraulic Cylinder

Clevis mounted hydraulic cylinders are designed for applications involving pivoting, articulated or angular movement. The clevis mounting arrangement allows the cylinder to follow movement of the connected mechanism while transmitting hydraulic force efficiently.

Suitable for industrial machinery, material-handling systems, lifting mechanisms and customized hydraulic equipment.

4. Hydraulic Cylinder for Goods Lift

AKURACY.ORG offers hydraulic cylinders for goods lifts and material lifting systems where dependable vertical movement and controlled lifting force are required.

Cylinder bore, stroke, lifting capacity, mounting and hydraulic configuration can be customized according to the lift design, travel requirement and rated load.

5. Hydraulic Cylinder for Passenger Lift

We offer custom hydraulic cylinders for passenger-lift applications based on the technical requirements of the lift system.

Bore diameter, stroke, mounting arrangement, working pressure and load requirements should be selected according to the complete lift design and applicable safety requirements.

6. Hydraulic Cylinder for Stacker

Our hydraulic cylinders for stackers are suitable for lifting and positioning applications in warehouses, factories, logistics operations and material-handling equipment.

Customized cylinders can be manufactured according to lifting height, load capacity, installation dimensions and mounting requirements.

7. Hydraulic Cylinder for Scissor Table & Scissor Lift

AKURACY.ORG supplies hydraulic cylinders for scissor tables, scissor lifts and lifting platforms designed for controlled lifting and lowering operations.

Cylinder capacity, bore, stroke and mounting arrangement can be selected according to platform dimensions, lifting height and rated load.

For specific scissor-lift designs, hydraulic system pressure can be configured according to the customer's engineering requirements.

8. Hydraulic Cylinder for Hydraulic Press

Our hydraulic press cylinders are designed for applications requiring high linear force for pressing, forming, punching, bending, assembly and other industrial processes.

Hydraulic press cylinders can be customized for:

• Pressing capacity

• Required stroke

• Bore and piston rod diameter

• Operating speed

• Mounting arrangement

• Single or double acting operation

• Hydraulic power-pack compatibility

9. Single Acting Hydraulic Cylinder

A single acting hydraulic cylinder uses hydraulic pressure to generate force primarily in one direction. Return movement may be achieved through spring force, external load or another mechanical arrangement depending on the application.

These cylinders are widely used for lifting, pushing, clamping, pressing and positioning operations.

10. Double Acting Hydraulic Cylinder

A double acting hydraulic cylinder uses hydraulic pressure for powered movement in both extension and retraction directions.

This configuration is suitable for applications requiring controlled forward and return movement, including industrial automation, presses, material-handling machinery, special-purpose machines and production equipment.

11. Telescopic Hydraulic Cylinder

Our telescopic hydraulic cylinders are suitable for applications requiring a long working stroke while maintaining a comparatively compact retracted cylinder length.

Multiple telescopic stages can provide extended travel for applications such as lifting systems, material handling, industrial equipment and customized hydraulic mechanisms.

Key Features

• Heavy-duty industrial hydraulic cylinder construction

• Sturdy cylinder barrel construction

• Hard chrome-plated piston rod options

• Smooth and controlled linear movement

• High-force capability for lifting, pushing and pressing

• Customized bore and stroke combinations

• Multiple mounting configurations

• Single acting and double acting options

• Telescopic cylinder solutions

• Designed for demanding industrial operating environments

• Custom engineering based on machine and application requirements

Customized Hydraulic Cylinder Manufacturing

Every hydraulic application can require a different combination of force, bore diameter, stroke, rod diameter, pressure, operating speed, mounting geometry and duty cycle.

AKURACY.ORG can develop hydraulic cylinders according to customer-specific requirements. For a customized quotation, customers may share:

• Required cylinder capacity in tonne or kN

• Bore diameter

• Stroke length

• Piston rod diameter

• Working pressure

• Single acting or double acting requirement

• Push / pull / push-and-pull operation

• Mounting type

• Closed and open cylinder length

• Operating speed

• Application details

• Installation drawing or available space

• Hydraulic power-pack details

• Required quantity

Industrial Applications

AKURACY.ORG hydraulic cylinders can be configured for applications including:

Hydraulic Presses | Goods Lifts | Lifting Platforms | Scissor Lifts | Stackers | Material Handling Equipment | Industrial Automation | Manufacturing Machinery | Construction Equipment | Heavy Engineering | Machine Tools | Special Purpose Machines | Pressing Systems | Lifting Systems | Pushing & Pulling Applications

Why Choose AKURACY.ORG?

AKURACY.ORG focuses on engineered industrial solutions where reliability, dimensional suitability and application-specific customization are important. Customers can obtain hydraulic cylinders designed around their actual equipment requirements rather than being restricted only to standard configurations.

With capabilities for large bore sizes, long strokes and high-capacity hydraulic applications, we support customers looking for standard as well as custom-built hydraulic solutions.

Need a Custom Hydraulic Cylinder?

Send us your required capacity, bore, stroke, pressure, mounting arrangement, application and quantity. Our team can review your requirement and propose a suitable hydraulic cylinder configuration.

Brand: AKURACY.ORG
Product: Hydraulic Cylinders & Custom Hydraulic Solutions
Bore: Up to 700 mm
Stroke: Up to 6 Metres
Capacity: Up to 500 Tonne
Price: On Request

Email: sales@akuracy.org
Direct Call / WhatsApp: +91 94038 91579
Website: www.akuracy.org

AKURACY.ORG – Custom Hydraulic Cylinders for Industrial Lifting, Pressing, Pushing, Pulling and Material-Handling Applications.
